Pad Covers

Leveling Feet

Save to My Project

What is this?

Product Information

Pad Covers fit over the bottom of our Leveling Feet and Stud Leveling Feet. These PVC covers provide increased grip to prevent sliding on sloped or uneven surfaces. They also provide cushioning to reduce transmitted machine vibrations and walking. Please note, rated leveling-foot load capacity is reduced to prevent damage to the cover. Available to fit Leveling Feet and Stud Leveling Feet with thread sizes from 3/8-16 to 3/4-10 (M10 to M20 in metric).

View in Catalog Page
Contact Customer Service
Contact Customer Service

Application Information

Pad Cover installed on a Stud Leveling Foot

Pad Covers help prevent sliding on sloped or uneven surfaces.

Material

MATERIAL	HEAT TREAT	FINISH	DFARS	RoHS
Polyvinyl chloride thermoplastic	-	-	✔	✔

Click here for detailed material and finish specifications.

California residents click here for Prop 65 information.

Pad Covers

PART NO.	FITS LEVELING FEET	A DIA	B	C DIA	D	LOAD RATING (lbs)
CL-6-RPC	3/8-16 and M10	1-1/2	.40	1.22	1/8	300
CL-8-RPC	1/2-13 and M12	2-1/8	.46	1.85	1/8	700
CL-10-RPC	5/8-11 and M16	2-3/4	.52	2.47	1/8	1200
CL-12-RPC	3/4-10 and M20	3-1/4	.72	3.00	1/8	1800
