ROEMHELD’s module ergonomic handling system includes a range of precision-engineered modules that support the lifting, rotating, and tilting of heavy workpieces during assembly. Each module is designed to improve operator safety, control, and comfort while enabling precise part positioning for efficient workflows. These modules can be used independently or combined to build a fully integrated, customizable assembly solution.
ROEMHELD Lifting Modules
ROEMHELD lifting modules are designed to elevate workpieces smoothly and securely to the ideal working height. These modules allow for precise vertical adjustment, enabling operators to maintain ergonomic posture during assembly and inspection. Available in a range of load capacities and stroke lengths, lifting modules are ideal for accommodating varying part sizes and production requirements. Primary benefits include:
• Manual or powered lift options
• Adjustable height for operator comfort
• Smooth, controlled movement to prevent strain or damage
ROEMHELD Rotating Modules
ROEMHELD Rotating Modules provide the flexibility to rotate heavy components with ease, offering either horizontal or vertical axis rotation depending on your application. These modules allow operators to access hard-to-reach areas of a workpiece, improving accuracy during complex assembly tasks. Rotating modules enhance productivity by allowing precise, repeatable orientation changes with minimal effort.
• Horizontal axis rotation is ideal for pivoting parts in a plane, such as rotating an engine block or housing from one side to another.
• Vertical axis rotation enables 360° turning of parts, making it easier to align features or switch assembly positions without manual repositioning.
ROEMHELD Tilting Modules
Tilting modules enable the angled positioning of workpieces, making it easier to assemble, weld, or inspect parts that are otherwise difficult to access. These modules offer controlled tilting movements, giving operators the ability to fine-tune the angle of the workpiece for better visibility and ergonomic access. By incorporating tilting modules into your workstation, you can improve assembly accuracy and reduce operator fatigue, especially when working with bulky or heavy components. Key features include:
• Smooth, adjustable tilting angles
• Manual or powered tilt mechanisms
• Secure locking to maintain part position during assembly
