Hydraulic Power Workholding: Fixture Design Guide

Selecting the right hydraulic fluid is critical for ensuring reliable performance, long service life, and efficient operation of hydraulic workholding systems. This guide provides key information on recommended hydraulic fluids, viscosity requirements, temperature considerations, and fluid compatibility to help maintain optimal system performance and prevent premature component wear.

Learn More

Hydraulic workholding components are rated for maximum operating pressures ranging from 70 to 500 bar (~1,000 to ~7,250 PSI). Understanding the relationship between system pressure, cylinder bore size, and output force is fundamental to fixture design. This section explains standard pressure ratings, design pressure selection, and minimum operating requirements for different power unit types.

Learn More

Hydraulic clamps are available in single-acting and double-acting configurations. Single-acting clamps use hydraulic pressure to generate clamping force while a spring returns the clamp to the open position. Double-acting clamps use hydraulic pressure for both clamping and retraction. Each configuration has distinct advantages depending on cycle time requirements, retraction force needs, and system complexity constraints.

Learn More

Effective fixture design positions locators to absorb machining forces rather than relying solely on clamping force. When locators are properly placed relative to cutting forces, smaller clamps can be used without sacrificing workpiece stability. This section covers locator placement strategies, cutting force directions for common machining operations, and methods for reducing required clamping force through fixture geometry.

Learn More

Determining required clamping force involves analyzing cutting forces, friction coefficients, and safety factors. While detailed calculations can become complex, simplified methods provide adequate guidance for most applications. This section presents practical approaches to clamping force estimation and compares hydraulic clamp output to equivalent manual clamping capacity.

Learn More

Work supports differ fundamentally from clamps. Rather than applying force to hold a workpiece, work supports extend until they contact the workpiece surface, then lock in position to prevent deflection during machining. Hydraulic work supports automatically compensate for surface variations and provide rigid backing against cutting forces. This section explains work support operation, selection criteria, and integration with clamping sequences.

Learn More

Some applications require both light clamping force and high support force in the opposite direction. Clamps with integral locking support plungers address this need by combining a low-force clamp with a self-locking support mechanism. These components are particularly suited for thin-walled parts where excessive clamping force would cause distortion. This section covers operating principles and application guidelines for these specialized clamps.

Learn More

Supplying fluid to hydraulic fixtures is not merely an afterthought. Fluid supply is an integral part of fixture design. The following Swing Clamp fixtures illustrate four distinct plumbing concepts.

Learn More

Many Roemheld Power Workholding components can be manifold mounted ... powered directly through fluid passages drilled in a fixture. This unique mounting capability eliminates tubing and hoses in the working area, for clean fixtures without chip traps. Even fluid passages longer than your drilling capacity are possible by drilling shorter passages in separate blocks, then connecting them using connecting inserts.

Learn More

Single-acting clamps and work supports contain internal spring chambers that must breathe as the piston moves. When fixtures operate in flood coolant environments, these air passages can draw cutting fluid into the mechanism, causing contamination and eventual malfunction. This section explains venting strategies that protect internal components while maintaining proper operation.

Learn More

Hydraulic clamping is usually fast, but not instantaneous. To estimate clamping time, consider the two phases of clamping: Extending time, under low-pressure free flow, and Pressure-building time.

Learn More

Hydraulic workholding circuits behave differently than manual clamping systems. Fluid mechanics, compressibility, and thermal effects create failure modes that do not exist with mechanical clamps. Understanding these pitfalls during the design phase prevents costly troubleshooting, rework, and fixture failures in production.

Learn More
